Rocksand
The system provides low detection limits and stable performance, meeting the requirements of applicable standards.
Three testing modes are provided to accommodate both on‑site and laboratory analysis requirements.
Supports integrated on‑site quantitative analysis for water and soil samples.
Industry‑specific solutions with a built‑in alert system for heavy metal content that exceeds acceptable thresholds.
仪器特点
One‑click testing enables efficient analysis of nearly 40 different elements, covering the heavy metal elements specified in relevant standards.
The localized technical service team is available to respond in a timely manner, offer technical support, and help safeguard customer interests.
The system supports quantitative analysis of low‑concentration elements, including Cr, Pb, As, Hg, and Cd.
Application Direction
Technical Specifications
X-ray Tube Voltage & Current：25-50kV, 200 μA, Power 10 W
Crystal：3 DCC Crystals
Detector：FAST SDD
System Electronics：512MB Dual-core Processor
Power Requirements：90-264VAC, 47 ~ 63Hz, 3A @ 115V； powered by analyzer battery
Radiation Safety：Radiation dose <1.0 μSv/h
Total Weight：<6.0 kg (13.2 lbs)
Test Stand Dimensions：25.4 x 21.8 x 37.8 cm
